PLA+, TOUGHNESS +
Compared with the standard PLA, the PLA+ improved the disadvantage of PLA toughness being not good. The printed parts quality still very good same with standard PLA.
WHY IT IS SPECIAL
PLA+ QUALITY TEST
Test the temperature characteristics of the consumables, and the consistency of the filaments. 190-230â„? The printing is complete,the filaments are uniform, the bridging continuity is good,and there is no stringing phenomenon. If you want to build the temperature tower, the cutting level is very high,and the stringing is more common, Need to focus on improvement.
Test the overall printing effect of filament at 196â„? speed 35mm/s, uniform and continuous filament output at 196â„? comes out very smooth printing surface.
XYZ cube The overall printing effect of testing filament at 210â„? speed 50mm/s, uniform and continuous filament output at 210â„? high gloss.
The overall printing effect of testing filament s at 220°C and 55mm/s speed. At 220°C,
the increase in speed will significantly improve the printing effect, with more uniform filament output and smoother printing surface
|physical properties||Typical Value:
|Peak melt Temperature:
|Glass Transition Temperature:
|MFR[g/10min](1)：Â?210â„?/ 2.16KG||6g/10 min||ISO 1133|
|Specific Gravity[g/cm3]ï¼?/td>||1.24 g/cm³||ISO 1183|
|moisture absorption 24hr[%](2) :
|moisture absorption 7day[%](2)||/||/|
|moisture absorption 4weeks[%](2)||/||/|
|Heat Deflection Temperature(0,45MPa):||60â„?/td>||ISO 75|
|Tensile Yield Strength Filament[MPa]:
||45 Mpa||ISO 527-1|
